posted
I'll try it out when I get a chance for a new box - it may work well as the single box does the best numbers for what it is cone area and power wise.
-------------------- - Jacob Fuller Posts: 990 | From: Mooresville, NC | Registered: Oct 2001
| IP: Logged |
posted
My in-car tuning may be lower than I imagined... the highest current should be right around tuning and my current continued to rise down to 40 Hz measuring it today.
I have not tested any lower frequencies than that yet - so I may have to cut off ALOT of port to get that tuning up to where I want it!
-------------------- - Jacob Fuller Posts: 990 | From: Mooresville, NC | Registered: Oct 2001
| IP: Logged |
Cut it down until it was reading 39 Hz - score was 0.2dB down but I couldn't get my PVC piece back in so it would have either been the same or 0.1-0.2 up.
Cut it down more until it was reading 41 Hz - lost 0.9 dB!
Re-built the port to 4" longer than before... simply taping it up against what was left of the old port and building a quick brace piece to hold the parts together in the center... no glue at all, no smoothing, nothing special.
I am within 0.1 dB of my score before cutting - 154.5 dB.
My iPod only has tracks down to 35 Hz and by the current measurement 35 Hz had the highest current... so the box is at least 2 Hz lower tuned than before.
-------------------- - Jacob Fuller Posts: 990 | From: Mooresville, NC | Registered: Oct 2001
| IP: Logged |
posted
Maybe going with a bigger opening(more port area) and less depth will raise your tuning to were you want it? What is the current length now that you added the 4"?
Posts: 262 | From: indiana | Registered: Aug 2008
| IP: Logged |
-------------------- TEAM DB UNIT (Master Yoda) 2006 Competition Only Hardcore Points Champion 2006 Competition Only Trunk Stock Points Champion 2007 Competition Only Trunk Stock Points Champion 2008 Competition Only Overall Points Champion http://www.competitiononly.com/ Authorized Second Skin Dealer www.secondskinaudio.com [IMG]
posted
I discovered *another* big hole in my floor board... so I think it is time to suck it up... pull the system and carpet out and weld up these holes.
This hole is pretty new since I started peaking in the 40s... I could stomp my foot down real hard and it would go through!
-------------------- - Jacob Fuller Posts: 990 | From: Mooresville, NC | Registered: Oct 2001
| IP: Logged |
quote:Originally posted by Ben Gailey: jacob, have you tried split pvc on the top of the box between the subs from the front of the box to the back of the box?
Not yet - I'll add that to my to-do list
I am in the process of fixing the giant hole in my floor in the Jeep, replacing the gas tank AGAIN (yes, the new tank sprung a leak), and changing out the carpet as it was soaked and rusting out the rest of my floor that didn't already have a big hole!
-------------------- - Jacob Fuller Posts: 990 | From: Mooresville, NC | Registered: Oct 2001
| IP: Logged |
posted
any idea what your jeep does with 2k watts i have a idea for street stock
-------------------- TEAM420 TEAM KINETIK TEAM MAXXSONICS T3AUDIO TEAM DCAUDIO SS 1-2 3rd PLACE 2007 INDY "REGIONALS" SS 1-2 1ST PLACE INDY AND 2008 NATIONAL CHAMPION.
posted
My new carpet is due today... so once I get that in I can start putting the system back in.
I decided to try 12v and see what happens. I have 6x Stinger SPV-70s for the time being. If I am happy with my 12v results I'll upgrade these to Powermaster D3100s - I got the Stingers CHEAP so I have a bunch of them.
I didn't post it in this thread before but I had a GIANT hole in my floor that fixed - hence taking the whole system and carpet out. My driver floor board was essentially gone.
-------------------- - Jacob Fuller Posts: 990 | From: Mooresville, NC | Registered: Oct 2001
| IP: Logged |
posted
probably better off with Stinger batts than Powermaster.
--------------------
2006 Street A - 152.7 Certified 2007 Street C - 154.8 Certified 2007 Street A - 154.4 Certified 2008 Street C - 156.3 Certified 2008 Street B - 156.6 Certified
TEAM FEAR OF BASS Posts: 3611 | From: Toronto, On, Canada | Registered: Feb 2001
| IP: Logged |
posted
Jacob already has D1000's. He is just gonna play with 12v for a while
-------------------- Team Outcast Team DB UNIT "Carolina Chapter" 1990 Honda CRX 2009 Iasca SBN Stock Pro 1 Champion 1989 Honda Civic Hatchback 2008 Iasca Adv. No Wall 1 North American Champion 2007 Db Drag 1st SM 3-4 and 4th Bass Race Florida Regionals 2007 2nd overall in US points and 9th overall in World 2007 Competion Only Pro and Hardcore Points Champion 2007 Meca M5 Points Champion and South Carolina Champion 2007 NSPL NW Points Champion 2007 NSPL Pro Points Champion 2006 NSPL Pro Points Champion
posted
you have the amp at rated impedance, plus you've got Really high impedance rise, and you're still getting rated power on 12V batteries? that's wild.
What are you rising to? 3ohm or higher?
Posts: 5502 | From: Columbus, OH - formerly FL | Registered: Oct 2003
| IP: Logged |
posted
oh, my bad. 2 amps, strapped at 1/2ohm per amp. makes more sense
Posts: 5502 | From: Columbus, OH - formerly FL | Registered: Oct 2003
| IP: Logged |
posted
Ah yes I remember seeing that one in the pic you sent me.How are you liking your new amps?They seem to be pretty stout. Posts: 262 | From: indiana | Registered: Aug 2008
| IP: Logged |
